Specifications
Manufacturer
MSI
Part #
- MPG B550 GAMING CARBON WIFI
- 7C91-002R
- B550GCARBWIFI
Socket / CPU
AM4
Form Factor
ATX
Chipset
AMD B550
Memory Max
128 GB
Memory Type
DDR4
Memory Slots
4
Memory Speed
- DDR4-1866
- DDR4-2133
- DDR4-2400
- DDR4-2666
- DDR4-2800
- DDR4-2933
- DDR4-3000
- DDR4-3200
- DDR4-3466
- DDR4-3600
- DDR4-3733
- DDR4-3866
- DDR4-4000
- DDR4-4133
- DDR4-4266
- DDR4-4400
- DDR4-4533
- DDR4-4600
- DDR4-4800
- DDR4-4866
Color
Black / Silver
SLI/CrossFire
CrossFire Capable
PCIe x16 Slots
2
PCIe x8 Slots
0
PCIe x4 Slots
0
PCIe x1 Slots
3
PCI Slots
0
M.2 Slots
- 2242/2260/2280 M-key
- 2242/2260/2280/22110 M-key
- 2230 E-key
Mini-PCIe Slots
0
Half Mini-PCIe Slots
0
Mini-PCIe / mSATA Slots
0
mSATA Slots
0
SATA 6.0 Gb/s
6
Onboard Ethernet
1 x 2.5 Gb/s (Realtek RTL8125B)
Onboard Video
Depends on CPU
USB 2.0 Headers
2
USB 2.0 Headers (Single Port)
0
USB 3.2 Gen 1 Headers
1
USB 3.2 Gen 2 Headers
1
USB 3.2 Gen 2x2 Headers
0
Supports ECC
No
Wireless Networking
Wi-Fi 6
RAID Support
Yes
Uses Back-Connect Connectors
No
Compatible Parts
- View Compatible CPU Coolers
- View Compatible CPUs
- View Compatible Cases
- View Compatible Memory
- View Compatible Optical Drives
- View Compatible Power Supplies
- View Compatible Sound Cards
- View Compatible Storage
- View Compatible Video Cards
- View Compatible Wired Network Adapters
- View Compatible Wireless Network Adapters
Prices
| Merchant | Base | Promo | Shipping | Tax | Availability | Total | |
|---|---|---|---|---|---|---|---|
|
$377.65 | +$22.33 s/h | In stock | $399.98 | Buy | ||
| ( 2 new from $377.65. Last updated 2 minutes ago. ) | |||||||
* Product prices and availability are accurate as of the date/time indicated and are subject to change. Any price and availability information displayed on Amazon.com at the time of purchase will apply to the purchase of this product.
* PCPartPicker may receive compensation for purchases made at participating retailers linked on this site. This compensation does not affect what products or prices are displayed, or the order of prices listed. Learn more here.
Price Alert
Specifications
Manufacturer
MSI
Part #
- MPG B550 GAMING CARBON WIFI
- 7C91-002R
- B550GCARBWIFI
Socket / CPU
AM4
Form Factor
ATX
Chipset
AMD B550
Memory Max
128 GB
Memory Type
DDR4
Memory Slots
4
Memory Speed
- DDR4-1866
- DDR4-2133
- DDR4-2400
- DDR4-2666
- DDR4-2800
- DDR4-2933
- DDR4-3000
- DDR4-3200
- DDR4-3466
- DDR4-3600
- DDR4-3733
- DDR4-3866
- DDR4-4000
- DDR4-4133
- DDR4-4266
- DDR4-4400
- DDR4-4533
- DDR4-4600
- DDR4-4800
- DDR4-4866
Color
Black / Silver
SLI/CrossFire
CrossFire Capable
PCIe x16 Slots
2
PCIe x8 Slots
0
PCIe x4 Slots
0
PCIe x1 Slots
3
PCI Slots
0
M.2 Slots
- 2242/2260/2280 M-key
- 2242/2260/2280/22110 M-key
- 2230 E-key
Mini-PCIe Slots
0
Half Mini-PCIe Slots
0
Mini-PCIe / mSATA Slots
0
mSATA Slots
0
SATA 6.0 Gb/s
6
Onboard Ethernet
1 x 2.5 Gb/s (Realtek RTL8125B)
Onboard Video
Depends on CPU
USB 2.0 Headers
2
USB 2.0 Headers (Single Port)
0
USB 3.2 Gen 1 Headers
1
USB 3.2 Gen 2 Headers
1
USB 3.2 Gen 2x2 Headers
0
Supports ECC
No
Wireless Networking
Wi-Fi 6
RAID Support
Yes
Uses Back-Connect Connectors
No
Price History
* Amazon pricing is not included in price history graphs.
- 3 points
- 12 days ago
from completed build Current Build - Ryzen 5600X & MSI RX 580 Armor OC, G.Skill Trident Z RGB 32GB RAM
At the point I bough this 5 years ago, it was a little bit at the high end, but it stands the test of time. AM4 CPUs are still relevant today. This motherboard offers everything you need in a modern budget PC, plus it offers Wi-Fi.
- 4 points
- 4 months ago
from completed build Beater with a sleeper
Very few bugs. Still holds up for anyone not trying to do anything insane.
- 4 points
- 1 year 9 months ago
from completed build Bloodlust
Great motherboard with lots of interesting features and two CPU power connectors for overclocking. Comparable to the ROG STRIX B550-F Gaming. Though long boot times do plague this board after changing BIOS settings.
- 7 points
- 2 years 4 months ago
from completed build AZZA 804 Pyramid build Ryzen 5 5600X + RTX 3070Ti
No issues at all. Needed to update BIOS for Ryzen CPU, but that went flawless.
- 6 points
- 2 years 8 months ago
from completed build 3070ti/5600x First Build
This mobo is really working for me, I did the bios flash back to pair it with my ryzen 5600x and it worked well.
- 8 points
- 2 years 11 months ago
from completed build Lian Li o11 Air Rebuild
Worked great for a while, now Bluetooth stopped working so I had to get an adapter.
- 2 points
- 2 years 11 months ago
from completed build My Battleship
Definitely gets the job done and has every thing I need on it But could use a few more USB slots and more shielding. It could use more RGB as the RGB that's on it is quite week. The BIOS is also very confusing but it shows basic stuff. Overall quite good though
- 5 points
- 3 years ago
from completed build First Personal Build
This motherboard is beautiful. Had everything I wanted WiFi 6 and all. The price dropped to $160 at some point and I really wish I had grabbed it then.
- 9 points
- 3 years ago
from completed build Hyperion - All AMD air cooled black and white theme
Great features and looks great.
Loses a star for needing BIOS upgrade before using with 5600X.
- 20 points
- 3 years 2 months ago
from completed build TRON Black & White Build
Works well for my purposes, Dragon software has gotten better since I originally purchased
