Specifications
Manufacturer
Asus
Part #
- Z170-A
- 90MB0LS0-M0EAY0
Socket / CPU
LGA1151
Form Factor
ATX
Chipset
Intel Z170
Memory Max
64 GB
Memory Type
DDR4
Memory Slots
4
Memory Speed
- DDR4-2133
- DDR4-2400
- DDR4-2666
- DDR4-2800
- DDR4-2933
- DDR4-3200
- DDR4-3300
- DDR4-3333
- DDR4-3400
Color
Black / White
SLI/CrossFire
- CrossFire Capable
- 2-Way SLI Capable
PCIe x16 Slots
3
PCIe x8 Slots
0
PCIe x4 Slots
0
PCIe x1 Slots
3
PCI Slots
1
M.2 Slots
2242/2260/2280/22110 M-key
Mini-PCIe Slots
0
Half Mini-PCIe Slots
0
Mini-PCIe / mSATA Slots
0
mSATA Slots
0
SATA 6.0 Gb/s
6
Onboard Ethernet
1 x 1 Gb/s
Onboard Video
Depends on CPU
USB 2.0 Headers
2
USB 2.0 Headers (Single Port)
0
USB 3.2 Gen 1 Headers
2
USB 3.2 Gen 2 Headers
0
USB 3.2 Gen 2x2 Headers
0
Supports ECC
No
Wireless Networking
None
RAID Support
Yes
Uses Back-Connect Connectors
No
Compatible Parts
- View Compatible CPU Coolers
- View Compatible CPUs
- View Compatible Cases
- View Compatible Memory
- View Compatible Optical Drives
- View Compatible Power Supplies
- View Compatible Sound Cards
- View Compatible Storage
- View Compatible Video Cards
- View Compatible Wired Network Adapters
- View Compatible Wireless Network Adapters
Build Videos Using This Part
Prices
| Merchant | Base | Promo | Shipping | Tax | Availability | Total | |
|---|---|---|---|---|---|---|---|
|
$262.27 | In stock | $262.27+ | Buy | |||
| ( 4 new from $262.27, 8 used from $111.21. Last updated 2 minutes ago. ) | |||||||
* Product prices and availability are accurate as of the date/time indicated and are subject to change. Any price and availability information displayed on Amazon.com at the time of purchase will apply to the purchase of this product.
* PCPartPicker may receive compensation for purchases made at participating retailers linked on this site. This compensation does not affect what products or prices are displayed, or the order of prices listed. Learn more here.
Price Alert
* Price alerts use your merchant selections and tax settings.)
* We do not issue price alerts for any Amazon price listings.
Specifications
Manufacturer
Asus
Part #
- Z170-A
- 90MB0LS0-M0EAY0
Socket / CPU
LGA1151
Form Factor
ATX
Chipset
Intel Z170
Memory Max
64 GB
Memory Type
DDR4
Memory Slots
4
Memory Speed
- DDR4-2133
- DDR4-2400
- DDR4-2666
- DDR4-2800
- DDR4-2933
- DDR4-3200
- DDR4-3300
- DDR4-3333
- DDR4-3400
Color
Black / White
SLI/CrossFire
- CrossFire Capable
- 2-Way SLI Capable
PCIe x16 Slots
3
PCIe x8 Slots
0
PCIe x4 Slots
0
PCIe x1 Slots
3
PCI Slots
1
M.2 Slots
2242/2260/2280/22110 M-key
Mini-PCIe Slots
0
Half Mini-PCIe Slots
0
Mini-PCIe / mSATA Slots
0
mSATA Slots
0
SATA 6.0 Gb/s
6
Onboard Ethernet
1 x 1 Gb/s
Onboard Video
Depends on CPU
USB 2.0 Headers
2
USB 2.0 Headers (Single Port)
0
USB 3.2 Gen 1 Headers
2
USB 3.2 Gen 2 Headers
0
USB 3.2 Gen 2x2 Headers
0
Supports ECC
No
Wireless Networking
None
RAID Support
Yes
Uses Back-Connect Connectors
No
Price History
* Amazon pricing is not included in price history graphs.
- 3 points
- 2 years 8 months ago
from completed build Customer Rig #33: Prebuilt Frankenstein
Couldn't overclock above 3200MHz on the RAM, but that's probably a Z170/first gen DDR4 trace layout issue more than this specific board, so won't count it against the board. Had no issues with it otherwise.
- 1 point
- 3 years 4 months ago
from completed build The Breeze Block (1st Build)
Aesthetically pleasing and I've had no issues with it.
- 4 points
- 5 years 4 months ago
from completed build MilanceX iCore
It's very good motherboard, there are some questions that I had, and couldn't find anywhere on motherboard manual. Also Asus support is not that good at helping when it comes to higher tier questions. Missing RGB.
- 10 points
- 6 years 1 month ago
from completed build First Gaming PC Build
"A racehorse." It's a great board but it's annoying as hell to a fault. There are a stupid amount of owners who suffer from the Boot_device_led problem, and I assume that the board just one day decides to read the wrong order of your drives. It's beautiful if it runs, but god is it a pain when it doesn't. Stay away from it, I will recommend ASROCK, MSI, or Gigabyte boards before ASUS now. I've had to open up to service my computer way too many times now, and it's not even because I want to. I've woken up to days where suddenly, my computer doesn't turn on anymore. This is my first product review, and I had to go out of my way to finally get rid of this culprit that's been causing me two years of headaches.
- 7 points
- 6 years 8 months ago
from completed build Mid-Range Gaming Build
One of the best boards ive worked with. Very easy and comprehendable.
- 5 points
- 7 years 2 months ago
from completed build Stryker
Good motherboard and price for the features but I'm taking off a star because the USB ports on my board failed after 3 months of usage. I was able to RMA it and get a replacement which has worked flawlessly so far.
- 7 points
- 7 years 2 months ago
from completed build White on Black - CIN5tx16
Nice to work with, easy and appealing UEFI BIOS. Glad I went with the Z chipset. The black and white theme is a nice touch.
- 7 points
- 7 years 2 months ago
from completed build Black Lightning - Gaming PC Build
Great mobo. got it on sale during black Friday. Great value for its price at 120$. no complaints.
- 28 points
- 7 years 2 months ago
from completed build Red Roses V 1.5
Brought over from my previous build. Overall it is a good board, but I do have one gripe with it. Do to some kind of bug with the LAN drivers that for the life of me I couldn't fix, the Ethernet port gave out on me after about 3 months of having it. After I toiled with it for a solid day I gave up trying to fix it and bought a PCIe card.
